CO2 Laser

The LM-50T is designed for the precise and efficient application of adhesive labels or films
on a variety of round bottles, including PET, plastic, glass, and metal bottles. With high-
speed capabilities and exceptional accuracy, this machine is ideal for labeling needs across
various industries.

Features:

• High Speed: Capable of up to 40 cycles per minute.
• Adjustable Positioning: Easily accommodates different bottle sizes, with a
  precision tolerance of ±1mm.
• Consistent Label Application: Ensures bubble-free, wrinkle-free, and high-quality
  labeling every time.
• Microprocessor-Controlled: Offers stable performance and reliable operation.
• Modular Design: Facilitates easy maintenance and quick troubleshooting.
• User-Friendly: Simple to operate with a well-thought-out design and precision
  engineering.

Model	ECL1130
Laser type	CO2 laser
Laser wave length	10.6um (10.2um, 9.3um optional)
Laser power	30W
Marking speed (character/s)	1300
Linear speed	300m/min*
Marking lines	Unlimited
Character height	0.8mm-within marking area
Font type	26 types of font, supports multi-language and user-defined fonts
Barcode type	1D barcode, 2D barcode
Graphic format	BMP/DXF/HPGL/JPEG
Text type	Point, line, arc. Rectangle, polygon, ellipse, circle
Variate	Serial number, text, date, time, counter, shift code
Marking area	50*50mm, 70*70mm, 110*110mm, 140*140mm, 175*175mm, 210*210mm
Focal distance	75mm, 100mm, 150mm, 200mm, 250mm, 300mm
Interface	10.1” touch screen, QWERTY or AZERTY virtual keyboard, shortcut icon-guided operation, help-online, Multi-language support, support Ethernet remote PC operation and networking
Cabinet material	Stainless steel + anodized aluminum
Product detection input	NPN/PNP/24V-detector
Production speed detection	Shaft encoder or synchronised signal
Signal input	Start up, stop, interlocking
Signal output	Operation status indication, smoke extraction purifier control, cooling device control, remote control
Communication port	RS-232, Ethernet (10/100 Mbit), USB port
Power supply	90-264V AC, 47-63Hz, 1000W/1300W (ECL 1160)
Cooling system	Air cooling
Operating temperature	5 – 40 ͦ C, 10%-90% RH, non-condensation
Protective grade	IP55, optional IP65
Optional	Infrared beam positioning, infrared beam focusing, network and remote control software (TCP/IP), USB backup storage suite, support set, smoke extraction purifier
